    24000 Bottles / H Leak Detection Machine Honeywell Pressure Sensor

    Ask Lasest Price
    Brand Name : T-LINE
    Model Number : TJSYJY08
    Certification : EcoVadis audit, UL certification, SGS certification, Sedex certification, European Union PED, American ASME, German TUV, Russian GOST, European Union ATEX, Australia AS1210, CE, ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 6 units per year
    Delivery Time : 120 days
    • Product Details
    • Company Profile

    24000 Bottles / H Leak Detection Machine Honeywell Pressure Sensor

    24000 Bottles / H Leak Detection Machine Honeywell Pressure Sensor



    Description:

    1. Leak detection equipment is a fully automated multi-function detection system equipment, the system is divided into two parts of the detection unit and a rejection unit. The detection unit includes: extrusion detection unit (module), liquid level detection unit (module). The stable speed is 24000 bottles/hour.


    2. The squeeze pressure unit uses squeeze and contact pressure sensing technology to detect. When the bottle passes through the testing machine, the double belts of the testing machine squeeze the bottle, and the pressure sensor behind the belt transmits the pressure value in real time, and the control center Analyze the pressure value and make a judgment. Thereby feedback whether there is any leakage after the product aluminum film is sealed; the signal is transmitted to the rejection device, and the unqualified product is rejected by the rejector.


    3. The liquid level detection unit adopts X-ray technology. After the low-energy photon source interacts with the measured substance, the intensity of the ray changes with the position of the detected material surface to control the detection of the filling liquid material capacity. Because of its non-contact measurement method, it fundamentally solves the problem that conventional weighing methods cannot measure the volume of liquid materials filled in the production line. Therefore, it is widely used in online detection of lubricants. The main structural characteristics of the detection unit: non-contact detection, fast detection speed, high precision; can work under the state of variable speed of the assembly line conveyor belt, not limited by the speed stability of the conveyor belt; the instrument has strong anti-interference ability and high reliability. Long-term stability is good; the number shows the cumulative number of qualified and unqualified products.


    Technical Parameters And Features:

    Material:

    304 stainless steel

    External power supply:

    AC380V/three-phase

    Power:

    2 KW

    Detection speed:

    24000 bottles/h

    Altitude:

    <3000 meters




    Testing Machine Accessories Brands:

    Display:

    Weiluntong, 10.1-inch touch screen;

    Pressure sensor:

    Honeywell

    Solenoid valve:

    US MAC;

    Cylinder:

    Japan SMC

    Ray launch tube:

    Oxford, UK

    Ray receiving tube:

    Japan Hamamatsu Photon

    High voltage power supply:

    American Spellman

    Optoelectronics:

    Germany Leuze

    Signal lights, circuit breakers:

    Schneider, France;

    Industrial fans:

    Australia Leizig;

    Encoder:

    Ike, Switzerland;

    Belt:

    Japan Misumi

    Motor:

    SEW, Germany

    Inverter:

    Danfoss, Denmark
