    500ml-2000ml Complete Monoblock Drinking Mineral Pure Water Bottle Filling Machine

    Ask Lasest Price
    Brand Name : Sunrise
    Certification : CE ISO
    Price : Negotiable price
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 6 units per year
    Delivery Time : 6 months
    • Product Details
    • Company Profile

    500ml-2000ml Complete Monoblock Drinking Mineral Pure Water Bottle Filling Machine

    Partial Products Main Technical Parameter:

    Model

    KSCGF08B

    KSCGF32A

    KSCGF40A

    KSCGF60A

    Capacity10000BPH15000BPH20000BPH30000BPH
    Rinser;24Rinser;32Rinser;40Rinser;60
    ModulesFiller;24Filler;32Filler;40Fille;60
    Seamer;8Seamer;8Searner;15Seamer;20
    Bottle typePET; D=50〜97mm; H=150~320mm
    Installed capacity5kw7kw9kw11kw
    Compressed air consumption0.6Nm3/min,0.6MPa0.8Nm3/min,0.6MPa1Nm3/min,0.6MPa1.2Nm3/min,0.6MPa
    Water consumption1.5~2m3/h,0.25MPa1.5~2m3/h,0.25MPa2.5 〜4m3/h,0.25MPa3.5~6m3/h,0.25MPa
    Size3000X2300X25003360X2540X25003550X3250X25005800X4500X2500
    Weight6t7.2t10t15t
    Washout rate100%
    Filling liquid level error±3mm
    Bottle damage rateW0.08%
    Domoge rate of bottle capW0.5%
    Sealing pass rateN99.7%
    Capping torque0.6〜2.8N.m Fluctuation range ± 15%
    Liquid loss rateW0.3%

    Electric Part & Safe Device & Automation:

    • When accident system automatic stop & alarm
    • Emergency switch when accident
    • Famous Mitsubishi brand PLC, Touch-screen Control Panel & inverter
    • Famous Omron brand sensor & other electric parts adopted, heavy duty running
    • Food Grade 304 stainless steel rinsing pump, reliable & sanitary


    Machine Base & Machine Construction:

    • 304 stainless steel frame
    • Tempering Glass window, Clear & no odor
    • Excellent start wheel design, easy change over parts
    • Machine Base with anti-rust process, ensure the forever antirus
    • All seal where liquid may Leakage & base neck come with rubber, water proof

    Q1: Do you have reference project?
    A1: We have reference project in most countries,If we get the permission of the customer who has brought the machines from us ,we can tell you their contact imformation,you can go to vist their factory.And you are always welcome to come to visit our company,and see the machine running in our factory,we can pick you up from the station near our city.
    Contact our sales people you can get video of our reference running machine


    Q2: Do you provide customized service
    A2: We can design the machines according your requirements(materil ,power,filling type,the kinds of the bottles,and so on),at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.


    Q3: What's your guarantee or the warranty of the quality if we buy your machines?
    A3: We offer you high quality machines with 1 year guarantee and supply life-long technical support.


    Q4: How long time for installation?
    A4: According your machines order,we will send one or two engineers to your plant,it will take about 10 days to 25 days.


    Installation service
    When you finish the Preparation conditions,our fast and professional aftersales service engineer team will go to your factory to install the machine,give you the operating manual,and train your employee until they can operate the machine well.


    The sample service
    1.We can send you the video of the running machine.
    2.You are welcome to come to visit our factory,and see the machine running.


    Customized service
    1.We can design the machines according your requirements(materil,power,filling type,the kinds of the bottles,and so on),at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.


    After-sales service
    1.We will delivery the machine and provide the bill of load on time to make sure you can get the machine quickly
    2.When you finish the Preparation conditions,our fast and professional aftersales service engineer team will go to your factory to install the machine,give you the operating manual,and train your employee until they can operate the machine well.
    3. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.
    4.We provide one year warranty
    5.Well-trained & experienced staff are to answer all your inquiries in English and Chinese
    6 .24 hours for engineer response (all services part 5days in customer hand by Intl' courier).
    7 .12 Months guarantee and life-long technical support.
    8.Your business relationship with us will be confidential to any third party.
    9. Good after-sale service offered, please get back to us if you got any questions.


    Quality Control
    We have the single quality department,that make sure the material of the raw materials is good,and ensure the machine running smoothly.
    If you want to know more information about the product,You can send an inquiry, we will solve any of your problems and send you running vedio.
