    Two Piece Tin Can Capping Machine Adapt Tank Diameter 66mm

    Ask Lasest Price
    Brand Name : SUNRISE
    Model Number : KLYG500
    Certification : EcoVadis audit, UL certification, SGS certification, Sedex certification, European Union PED, American ASME, German TUV, Russian GOST, European Union ATEX, Australia AS1210, CE, ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 6 units per year
    Delivery Time : 120 days
    • Product Details
    • Company Profile

    Two Piece Tin Can Capping Machine Adapt Tank Diameter 66mm

    Two-piece tin can capping machine KLYG500 series Product introduction:
    Body made of stainless steel, attractive appearance, durability. Network with a large contact area with the platen edge, stable and smooth operation mesh belt, mesh belt effectively prevent jumper. The blade portion in close contact with the master plate, the cover effectively improve the hanging rate. The overall coverage rate is high, the speed is fast, and the performance is reliable. All parts in contact with the water tank are made of ultra high molecular weight polyethylene, nylon, polyurethane, and other soft materials, the tank can effectively prevent scratches. High intelligence, with multi-point detection means, ensure that the host timely stop under abnormal circumstances, the operation of the host to ensure accurate and stable, and improve the stability of the device; gland synchronous transmission section linked manner, capping success rate. The height of the main machine capping device is adjustable to meet the capping requirements of different tank types.


    Product Properties


    1. Production capacity:200-250 cans/minute
    2. Total power:3kw
    3. Total weight:700kg
    4. Power supply:3X380VX50Hz
    5. Control power supply:DC24V/AC24V
    6. Compressed air source:0.8Mpa
    7. Air consumption:1.6m3/min
    8. Dimensions:gland part 1270mm×870mm×1800mm
    Cover part 1230mm×1000mm×3100mm
    9. The conveying floor height is1150mm±50mm.
    10. Adapt to the tank height range:89-130mm
    11. Adapt to tank diameter:66mm.


    Accessories Brand:
    1. PLC: German Siemens (Siemens)
    2. Motor reducer: Wanlian
    3. Sensor: SICK Korea Autonics (autonics)
    4. Touch screen: Taiwan Vinylon (weinview)
