    30 Boxes Per Minute Single Channel Gantry Palletizer

    Ask Lasest Price
    Brand Name : SUNRISE
    Model Number : KLMMD30D
    Certification : EcoVadis audit, UL certification, SGS certification, Sedex certification, European Union PED, American ASME, German TUV, Russian GOST, European Union ATEX, Australia AS1210, CE, ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 6 units per year
    Delivery Time : 120 days
    • Product Details
    • Company Profile

    30 Boxes Per Minute Single Channel Gantry Palletizer

    30 Boxes Per Minute Single Channel Gantry Palletizer


    Product introduction:


    30 boxes/minute gantry-type automatic low-position palletizer is to put the materials into the container (such as: carton, film package, etc.) or the packaged and unpackaged regular items on the pallet according to a certain arrangement. Automatic stacking and output are convenient for the next step of packaging or forklift transportation to warehouse for storage. The realization of intelligent operation management can greatly reduce labor and labor intensity. The LMMD palletizer adopts a 90-degree layout for in-box conveying and forming and pushing boxes. Its performance reaches the level of imported equipment of the same type. Standard functions include: storage and distribution of stacking boards; arrangement and forming of boxes; stacking and stacking of boxes; output of whole stacks. Other functions can be added according to user needs.


    Product properties


    1. Model:KLMMD30D
    2. Operation method:horizontal tray type
    3. Production capacity:30 boxes/min (4X6)
    4. Tray size:refer to 1200X1100
    5. Carton size:150-450 (length and width), 150-400 (height)
    6. Arrangement:According to customer requirements
    7. Pallet stacking compartment:10 pallets as a benchmark
    8. Power consumptionPower source: 19Kw
    Air: 200L/min
    9. Stacking limitPallet conveyor: 2 trays
    10. Equipment size (approximately)Length 11500 × Width 6000 X Height 4300
    Weight: 5500kg
    11. Conveyor height (approximately)Into the box: 800mm
    Unstack: 600mm
    12. Stacking board storage:automatically supply 10 ~ 15 stacking boards


    Main structure and characteristics


    1. It adopts high-quality rectangular steel pipe gantry stand with good structural rigidity.
    2. Using counterweights to balance the power of the lifting platform, reducing power consumption during start and stop.
    3. The main drive reducer adopts SEW's products, and the power output is stable.
    4. The working process, starting and final steps are all slow and stable, running fast in the middle, shortening non-working time, and high productivity.
    5. AirTAC pneumatic components and advanced electronic control technology reduce the risk of equipment downtime.
    6. In addition to the protective cover net, this machine is also equipped with a photoelectric safety protection device, which has a high degree of safety performance.
    7. The machine has low noise and uses oil-free lubricated pneumatic components to avoid oil pollution.
    8. It adopts touch screen operation, man-machine dialogue, adjustable palletizing method, display production speed, failure reason and location.
    9. It can accommodate 10-12 empty pallets, which can be automatically distributed.
    10. Set up a unique turning box in-position detection function, so that the molding failure can be handled quickly and quickly
